HTML5 Canvas 3D Sphere

HTML5 Canvas 3D Sphere

Our new tutorial tells us about creation of animated 3D Sphere (through direct access to pixels of canvas). The sphere itself is getting around the canvas continuously. This example should work in the most of modern browsers (like Firefox, Chrome, Safari and even in IE).





In the result, you should to get something like this:

HTML5 Canvas 3D Sphere



Step 1. HTML

This is markup of our result page. Here it is.

index.html

HTML
<div class="container">
    <canvas id="slideshow" width="1024" height="631"></canvas>
    <canvas id="obj" width="256" height="256"></canvas>
</div>

I prepared 2 canvas objects here: first one for source image, and the second one – to our Sphere.

Step 2. CSS

css/main.css

CSS
.container {
    height: 631px;
    margin: 50px auto;
    position: relative;
    width: 1024px;
    z-index: 1;
}
#obj {
    position: absolute;
    z-index: 2;
}

We should put our Sphere object above our main canvas.

Step 3. JS

js/script.js

JavaScript
var canvas, ctx;
var canvasObj, ctxObj;
var iDstW = 256;
var iDstH = 256;
var iXSpeed = 4;
var iYSpeed = 3;
var iLastX = iDstW / 2;
var iLastY = iDstH / 2;
var oImage;
var aMap = [];
var aBitmap;

var mathSphere = function(px, py) {
    var x = px - iDstW / 2;
    var y = py - iDstH / 2;
    var r = Math.sqrt(x * x + y * y);
    var maxR = iDstW / 2;
    if (r > maxR) return {'x':px, 'y':py};

    var a = Math.atan2(y, x);
    var k = (r / maxR) * (r / maxR) * 0.5 + 0.5;
    var dx = Math.cos(a) * r * k;
    var dy = Math.sin(a) * r * k;
    return {'x': dx + iDstW / 2, 'y': dy + iDstH / 2};
}

window.onload = function(){

    // load background
    oImage = new Image();
    oImage.src = 'images/bg.jpg';
    oImage.onload = function () {

        // creating canvas and context objects
        canvas = document.getElementById('slideshow');
        ctx = canvas.getContext('2d');
        canvasObj = document.getElementById('obj');
        ctxObj = canvasObj.getContext('2d');

        // clear context
        ctx.clearRect(0, 0, ctx.canvas.width, ctx.canvas.height);

        // and draw source image
        ctx.drawImage(oImage, 0, 0);

        aBitmap = ctx.getImageData(0, 0, iDstW, iDstH);
        for (var y = 0; y < iDstH; y++) {
            for (var x = 0; x < iDstW; x++) {
                var t = mathSphere(x, y);
                aMap[(x + y * iDstH) * 2 + 0] = Math.max(Math.min(t.x, iDstW - 1), 0);
                aMap[(x + y * iDstH) * 2 + 1] = Math.max(Math.min(t.y, iDstH - 1), 0);
            }
        }

        // begin updating scene
        updateScene();
    };

    function updateScene() {

        // update last coordinates
        iLastX = iLastX + iXSpeed;
        iLastY = iLastY + iYSpeed;

        // reverse speed
        if (iLastX > ctx.canvas.width - iDstW/2) {
            iXSpeed = -3;
        }
        if (iLastX < iDstW/2) {
            iXSpeed = 3;
        }
        if (iLastY > ctx.canvas.height - iDstH/2) {
            iYSpeed = -3;
        }
        if (iLastY < iDstH/2) {
            iYSpeed = 3;
        }

        // shifting of the second object
        canvasObj.style.left = iLastX - Math.floor(iDstW / 2) + 'px';
        canvasObj.style.top = iLastY - (Math.floor(iDstH / 2)) + 'px';

        // draw result Sphere
        var aData = ctx.getImageData(iLastX - Math.ceil(iDstW / 2), iLastY - Math.ceil(iDstH / 2), iDstW, iDstH + 1);
        for (var j = 0; j < iDstH; j++) {
            for (var i = 0; i < iDstW; i++) {
                var u = aMap[(i + j * iDstH) * 2];
                var v = aMap[(i + j * iDstH) * 2 + 1];
                var x = Math.floor(u);
                var y = Math.floor(v);
                var kx = u - x;
                var ky = v - y;
                for (var c = 0; c < 4; c++) {
                    aBitmap.data[(i + j * iDstH) * 4 + c] =
                      (aData.data[(x + y * iDstH) * 4 + c] * (1 - kx) + aData.data[((x + 1) + y * iDstH) * 4 + c] * kx) * (1-ky) +
                      (aData.data[(x + (y + 1) * iDstH) * 4 + c] * (1 - kx) + aData.data[((x + 1) + (y + 1) * iDstH) * 4 + c] * kx) * (ky);
                }
            }
        }
        ctxObj.putImageData(aBitmap,0,0);

        // update timer
        setTimeout(updateScene, 16);
    }
};

During initialization, the script is preparing two canvas objects and two contexts. Then, it loads our main background image, and draw it at our first context. After it prepares hash table of sphere transformations: aMap. And, in the end – it starts timer which updates main scene. In this function (updateScene) we update coordinates of our Sphere object, and draw updated sphere at our second context.
